4.2.4 Pumps
This page resumes all setting for the water pumps management. For more details about this
parameters and the pump control logic refer to section 0.
Setpoint/Sub-Menu
Default
Range
Description
Evap Pmp Ctrl=
#1 Only
#1 Only
#2 Only
Auto
#1 Primary
#2 Primary
Set number of evaporator pumps operational and their priority
Cond Pmp Ctrl=
#1 Only
#1 Only
#2 Only
Auto
#1 Primary
#2 Primary
Set number of condenser pumps operational and their priority (W/C only)
Recirc Tm=
30s
15…300s
Recirculation water timer
Evap Pmp 1 Hrs=
0h
Running Hours Evaporator Pump 1 (if present)
Evap Pmp 2 Hrs=
0h
Running Hours Evaporator Pump 2 (if present)
Cond Pmp 1 Hrs
0h
Running Hours Condenser Pump 1 (if present W/C only)
Cond Pmp 2 Hrs=
0h
Running Hours Condenser Pump 2 (if present W/C only)
4.2.5 Date/Time
This page will allow to adjust the time and date in the UC. This time and date will be used in the
alarm log. Additionally it’s also possible to set the starting and ending date for the DayLight Saving
time (DLS) if used.
Setpoint/Sub-Menu
Default
Range
Description
Actual Time=
12:00:00
Actual Date=
01/01/2014
UTC Diff=
-60min
Difference with UTC
DLS Enable=
Yes
No, Yes
DLS Strt Month=
Mar
DayLight Saving time start month
DLS Strt Week=
2ndWeek
DayLight Saving time start week
DLS End Month=
Nov
NA, Jan…Dec
DayLight Saving time end month
DLS End Week=
1stWeek
1
st
…5
th
week
DayLight Saving time end week
On board real time clock settings are maintained thanks to a battery mounted on the controller.
Make sure that the battery is replaced regularly each 2 years (see section 3.6).
4.2.6 Power Conservation
This page resumes all the settings that allows chiller capacity limitations. For more details about
these parameters and the functions LWT Reset and Demand Limit refer to section 5.1.7.
Setpoint/Sub-Menu
Default
Range
Description
Unit Capacity
-
-
Displays current unit capacity
Demand Limit=
-
-
Displays current demand limit
Lwt reset Type=
None
None
4-20mA
Return
OAT (A/C only)
Set leaving water temperature setpoint reset type
Refer to section
Max Reset Dt=
5°C
0.0…10.0°C
Refer to section
Start Reset Dt=
5°C
0.0…10.0°C
Refer to section
Cooling
Max Reset OAT=
23.8°C
10.0…29.4°C
Refer to section (A/C only)
Start Reset OAT=
15.5°C
10.0…29.4°C
Refer to section (A/C only)
Heating
Max Reset OAT=
0.0°C
10.0…-10.0°C
Refer to section (A/C-H/P only)
Start Reset OAT=
6.0°C
10.0…-10.0°C
Refer to section (A/C-H/P only)
