EWWQ090G ÷ EWWQ720L - R410a - Water-cooled scroll chillers
EWLQ090G ÷ EWLQ720L - R410a - Condenser less
EWHQ100G ÷ EWHQ400G - R410a - Heat pump scroll chillers
EWAQ- - R410a - Air-cooled scroll chillers
EWAQ-G - R410a - Air-cooled scroll chillers
EWYQ- - R410a - Air-cooled scroll heat pumps
Air and Water cooled scroll chillers & heat pump
Operation
Manual
Operation Manual
18
EWWQ - EWLQ - EWHQ
EWAQ - EWYQ
Air or Water cooled scroll chiller &
heat pump
D-EOMHW00106-15EN
Extension modules
BSP LED
BSP LED
Mode
Solid Green
BSP running
Solid Red
Hardware Error (*)
Flashing Red
BSP Error (*)
Flashing Red/Green
BSP upgrade mode
BUS LED
BUS LED
Mode
Solid Green
Communication running, I/O working
Solid Yellow
Communication running but parameter from the application wrong or missing, or uncorrect factory calibration
Solid Red
Communication down (*)
Communication modules
BSP LED (same for all modules)
BSP LED
Mode
Solid Green
BPS running, communication with controller
Solid Yellow
BSP running, no communication with controller (*)
Solid Red
Hardware Error (*)
Flashing Red
BSP Error (*)
Flashing Red/Green
Application/BSP update
(*) Contact Service.
LON module BUS LED
BUS LED
Mode
Solid Green
Ready for Communication. (All Parameter loaded, Neuron configured). Doesn't indicate a communication
with other devices.
Solid Yellow
Startup
Solid Red
No Communication to Neuron (internal error, could be solved by downloading a new LON application)
Flashing
Yellow
Communication not possible to the Neuron. The Neuron must be configured and set online over the LON
Tool.
Bacnet MSTP BUS LED
BUS LED
Mode
Solid Green
Ready for Communication. The BACnet Server is started. It doesn't indicate a active communication
Solid Yellow
Startup
Solid Red
BACnet Server down. Automatically a restart after 3 seconds are initiated.
Bacnet IP BUS LED
BUS LED
Mode
Solid Green
Ready for Communication. The BACnet Server is started. It doesn't indicate a active communication
Solid Yellow
Startup. The LED stays yellow until the module receives a IP Address, therefore a link must be established.
Solid Red
BACnet Server down. Automatic restart after 3 seconds is initiated.
Modbus BUS LED
BUS LED
Mode
Solid
Green
All Communication running
Solid
Yellow
Startup, or one configured channel not communicating to the Master
Solid Red
All configured Communications down. Means no communication to the Master. The timeout can be configured.
In case that the timeout is zero the timeout is disabled.
