Air cooled inverter water chiller
OPERATION
MANUAL
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Operation Manual
13
2 GENERAL DESCRIPTION
2.1 General
Microtech® III is a system for controlling single or dual-circuit air-cooled liquid chillers. Microtech®
III controls compressor start-up necessary to maintain the desired heat exchanger leaving water
temperature. In cooling mode it controls the operation of the fans to maintain the correct
condensing pressure in each circuit.
Safety devices are constantly monitored by Microtech® III to ensure their safe operation.
Microtech® III also gives access to a Test routine covering all inputs and outputs. All Microtech® III
controls can work in accordance with three independent modes:
Local mode: the machine is controlled by commands from the user interface.
Remote mode: the machine is controlled by remote contacts (volt-free contacts).
Network mode: the machine is controlled by commands from a BAS system. In this case, a data
communication cable is used to connect the unit to the BAS.
When the Microtech® III system operates autonomously (Local or Remote mode) it retains all of its
own control capabilities but does not offer any of the features of the Network mode.
2.2 Abbreviations used
In this manual, the refrigeration circuits are called circuit #1 and circuit #2. The compressor in
circuit #1 is labelled Cmp1. The other in circuit #2 is labelled Cmp2.
The following abbreviations are used frequently:
UC
Unit controller (Microtech III)
HMI
Human Machine Interface
CP
Condensing Pressure
EP
Evaporating Pressure
CSRT
Condensing Saturated Refrigerant Temperature
ESRT
Evaporating Saturated Refrigerant Temperature
ST
Suction Temperature
DT
Discharge Temperature
SSH
Suction SuperHeat
DSH
Discharge Superheat
EXV
Electronic Expansion Valve
ELWT
Evaporator Leaving Water Temperature
EEWT
Evaporator Entering Water Temperature
