Je bekijkt pagina 5 van 28
EUWY(*)5~24KBZW1
Packaged reversible air to water heat pumps
4PW61655-1 – 07.2010
Installation and operation manual
2
OPTIONS AND FEATURES
Refer to the engineering data book for the complete list of
specifications, options and features.
Options
■ Glycol application for chilled water temperature down to –10°C
or –5°C.
■ BMS-connection MODBUS (optional kit address card
EKAC10C)
(1)
■ Remote user interface (optional kit EKRUMCA). (Necessary to
additionally install kit address card EKAC10C.)
(1)
Features
■ Voltage free contacts
- general operation
- alarm
- operation compressor 1
- operation compressor 2
■ Changeable remote inputs
Following functions can be assigned to a total of 2 digital inputs.
- remote start/stop
- remote cooling/heating
- dual setpoint
TECHNICAL SPECIFICATIONS
Single circuit units
Double circuit units
(1) When EKAC10C is used in combination with remote user controller
EKRUMCA then it is not possible to use the BMS-connection MODBUS.
Unit (Hp) 5 8 10 12
Version N P B N P B N P B N P B
Dimensions HxWxD
(mm)
1230x1290x734 1230x1290x734 1450x1290x734 1450x1290x734
Weight
• machine weight
(kg)
163 181 193 227 241 253 258 272 284 258 272 284
• operation weight
(kg)
165 184 252 230 244 312 261 275 343 261 275 343
Connections
•water inlet
MBSP
1-1/4" 1-1/4" 1-1/4" 1-1/4"
•water outlet
MBSP
1-1/4" 1-1/4" 1-1/4" 1-1/4"
Internal water volume
(l)
2359335933593459
Expansion vessel
•Volume
(l)
—1212—1212—1212—1212
• Pre-pressure
(bar)
— 1.5 1.5 — 1.5 1.5 — 1.5 1.5 — 1.5 1.5
Safety valve water circuit (bar) — 1x 3.0 1x 3.0 — 1x 3.0 1x 3.0 — 1x 3.0 1x 3.0 — 1x 3.0 1x 3.0
Unit (Hp) 16 20 24
Version N P B N P B N P B
Dimensions HxWxD
(mm)
1321x2580x734 1541x2580x734 1541x2580x734
Weight
• machine weight
(kg)
455 473 485 516 534 546 516 534 546
• operation weight
(kg)
461 483 550 522 544 612 522 544 612
Connections
•water inlet
MBSP
2" 2" 2"
•water outlet
MBSP
2" 2" 2"
Internal water volume
(l)
69656106661066
Expansion vessel
•Volume
(l)
—1212—1212—1212
• Pre-pressure
(bar)
— 1.5 1.5 — 1.5 1.5 — 1.5 1.5
Safety valve water circuit (bar) — 1x 3.0 1x 3.0 — 1x 3.0 1x 3.0 — 1x 3.0 1x 3.0
