9 | Appendix
Application Guide
38
EKRACP* + EKRCTR* + EKRMIB* + EKRRVA* + EKRSEN* + EKRSIB* +
EKRUFH*
Daikin Home Controls
4P701747-1A – 2023.10
h Underfloor heating
INFORMATION
This configuration is based upon the Daikin Altherma unit operating on LWT instead
of ext. RT.
The HT waterzone is equipped with radiators. Per radiator, a DHC Radiator
Thermostat is added, which will regulate based upon the set temperature.
To set up the configuration, you need to:
1 Connect the DHC Radiator Thermostats,
2 (Optional) Add a DHC Room Thermostat — 1,
3 (Optional) Configure the DHC Room Thermostat — 1.
To connect the DHC Radiator Thermostats
INFORMATION
ALWAYS keep a minimum distance of 50cm between the accessories.
INFORMATION
You can cancel the connecting procedure by briefly pressing the system button again.
This will be indicated by the accessory LED lighting up red.
INFORMATION
If no connecting operations are carried out, connection mode is exited automatically
after 3 minutes.
INFORMATION
If you want to add another accessory to the existing ones, you first have to activate
connection mode of the existing accessory and afterwards the connection mode of
the new accessory.
You should connect all accessories in one room with each other. You can directly
connect a DHC Radiator Thermostat to another DHC Radiator Thermostat. To do
so, connection mode of both accessories has to be activated. To do this, proceed
as follows:
1 Open the battery compartment by pulling it down.
2 Remove the insulation strip from the battery compartment.
3 Long press the system button until the LED starts to flash orange.
