User’s Manual EM11A015H
intelligent Touch Manager
337
<Schedule Setup List>
Setting
location
Item Setting details
Possible range [
: Visible, : Conditionally visible, ×: Invisible, Between ( ) : Numerical range]
Remarks
Management point type
AreaIndoor Ventilator Chiller
Dio
Analog
(Ao)
MultiState
(Mo)
outdoor
Indoor
Hydrobox
AHU Ventilator D3Chiller InvChiller Chiller
Event Setup Screen
Common tab
Start
*14
× × ×
Pre–Cool × × × × × ×
× × × ×
Pre–Heat × × × × × × × × × ×
Stop
*14
× × ×
Setback high *1 *1*14 × × × × × × × × × *1
Setback Low
*1 *1*14 × × × × × × × × × *1
On/
Off
Pre–Cool/
Pre–Heat
Setpoint
Celsius Example: 25.0°C
*7*11
(16.0~32.0°C)
× × × × × × × × × ×
*7*11
(16.0~32.0°C)
Fahrenheit Example: 77°F
*7*11
(60~90°F)
× × × × × × × × × ×
*7*11
(60~90°F)
Filter Sign
Only Detailed
Setup for
centralized
monitoring
Dust Alarm Reset
Dust Alarm Forced Reset
R32 Alarm Stop
R/C Prohibition tab
R/C Prohibition
Start/Stop
Permitted
× × × × × ×
Stop Only
*15
×
× × × × ×
Prohibited
*15
×
× × × × ×
Operation Mode
Permitted
× × × × × × ×
Prohibited × × × × × × ×
Setpoint
Permitted
× × × × × × ×
Prohibited
*16
× ×
× × × × ×
A/C tab
Operation Mode
Fan
*10
× × × × × × × × × ×
*10
Cool
*10
× *19 × × × ×
*10
Heat
*10
× *20 × × × ×
*10
Dependent
*10
× × × × × × × × × ×
*10
Automatic
*10
× × × × × × × × × ×
*10
Dry
*2*10 × × × × × × × × × × *2*10
Setpoint
Setpoint
Celsius Example: 30°C
*7*9*10
(–30.0~70.0°C)
*7*9
(–30.0~70.0°C)
*7
(–30.0~70.0°C)
× × × × × × × ×
*7*9*10
(–30.0~70.0°C)
Fahrenheit Example: 90°F
*7*9*10
(–22~158°F)
*7*9
(–22~158°F)
× × × × × × × × ×
*7*9*10
(–22~158°F)
Shift
Amount
Celsius
Decrease the temperature
settings by 4°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 3°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 2°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 1°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 1°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 2°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 3°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 4°C
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Fahrenheit
Decrease the temperature
settings by 7°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 6°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 5°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 4°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 3°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 2°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Decrease the temperature
settings by 1°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 1°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 2°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 3°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 4°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 5°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 6°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Increase the temperature
settings by 7°F
*7*8*10 *7*8*17
× × × × × × × × ×
*7*8*10
Leaving water
setpoint
Celsius Example: 30°C × × × ×
*7
(–30.0~70.0°C)
× × × × × × ×
Fahrenheit Example: 90°F × × × ×
*7
(–22~158°F)
× × × × × × ×
Leaving water
setpoint(Cool)
Celsius Example: 30°C ×
*7
(–30.0~70.0°C)
× × ×
*7
(–30.0~70.0°C)
*7
(–30.0~70.0°C)
× × × ×
*7
(–30.0~70.0°C)
Fahrenheit Example: 90°F ×
*7
(
–22~158°F
)
× × ×
*7
(
–22~158°F
)
*7
(
–22~158°F
)
× × × ×
*7
(–22~158°F)
Leaving water
setpoint(Heat)
Celsius Example: 30°C ×
*7
(25.0~80.0°C)
× × ×
*7
(25.0~80.0°C)
*7
(25.0~80.0°C)
× × × ×
*7
(25.0~80.0°C)
Fahrenheit Example: 90°F ×
*7
(77~176°F)
× × ×
*7
(77~176°F)
*7
(77~176°F)
× × × ×
*7
(77~176°F)
Fan Speed
Low
× × × × × × × × × ×
Middle × × × × × × × × × ×
High × × × × × × × × × ×
Auto × × × × × × × × × ×
Airow Direction
Airow direction 0
Only Detailed
Setup for
centralized
monitoring
Airow direction 1
Airow direction 2
Airow direction 3
Airow direction 4
Swing
