8 Relocation
Installation and operation manual
11
BS4~12A14AJV1B9
VRV 5 branch selector unit
4P797565-1 – 2024.11
Malfunction Measure
If the system does not
operate at all.
Check if there is no power failure. Wait until
power is restored. If power failure occurs
during operation, the system automatically
restarts immediately after power is restored.
Check if no fuse has blown or breaker is
activated. If necessary, change the fuse or
reset the breaker.
If the problem persists, contact your installer
If a refrigerant leak
occurs (error code
/ )
Actions will be taken by the system. Do NOT
turn OFF the power supply.
Contact your installer and report the error
code.
If a safety device such
as a fuse, a breaker
or an earth leakage
breaker frequently
actuates.
Turn off the main power switch.
Contact your installer
If water leaks from the
unit.
Stop the operation.
Contact your installer.
Other issues Contact your installer. State the symptoms,
the complete model name of the unit (with
manufacturing number if possible) and the
installation date (possibly listed on the
warranty card).
After checking all the items above, if it is impossible to fix the
problem yourself, contact your installer and state the symptoms, the
complete model name of the unit (with manufacturing number if
possible) and the installation date.
7.1 Symptoms that are NOT system
malfunctions
The following symptoms are NOT system malfunctions:
7.1.1 Symptom: noise
▪ A "zeen" sound is heard immediately after the power supply is
turned on. The electronic expansion valve inside the BS unit starts
working and makes the noise. Its volume will reduce in about a
minute.
▪ A continuous low hissing sound is heard when the system is in
cooling or defrost operation. This is the sound of refrigerant gas
flowing through the BS unit.
▪ A hissing sound originating from the 4-way valve in the outdoor
unit which is heard at the start or immediately after stopping
operation or defrost operation, or when switching from cooling to
heating operation and vice versa.
8 Relocation
Contact your dealer to remove and reinstall the entire unit. Moving
units requires technical expertise.
9 Disposal
This unit uses hydrofluorocarbon. Contact your dealer when
discarding this unit. It is required by law to collect, transport and
discard the refrigerant in accordance with the "hydrofluorocarbon
collection and destruction" regulations.
NOTICE
Do NOT try to dismantle the system yourself: dismantling
of the system, treatment of the refrigerant, oil and other
parts MUST comply with applicable legislation. Units
MUST be treated at a specialised treatment facility for
reuse, recycling and recovery.
For the installer
10 About the box
NOTICE
Before installation, check the packaging and parts for
damage. Make sure that the shipment is complete.
NOTICE
When you carry or manipulate the unit, never tilt it more
than 70 degrees in any direction.
70°max.
Keep the following in mind:
▪ At delivery, the unit MUST be checked for damage and
completeness. Any damage or missing parts MUST be reported
immediately to the claims agent of the carrier.
▪ Bring the packed unit as close as possible to its final installation
position to prevent damage during transport.
▪ Prepare in advance the path along which you want to bring the
unit to its final installation position.
