7 | Smart Grid application
Installer reference guide
44
BRP069A61+BRP069A62
Daikin Altherma LAN adapter
4P464229-1E – 2023.11
INFORMATION
▪ In the "Forced ON" operation mode, energy buffering happens WITHOUT power
limitation.
▪ To get the most out of the energy buffering it is recommended to make use of
dynamic power limitation by way of an electricity meter.
▪ The electrical heaters will ONLY operate when the power limitation is higher than
the power rating of the heaters.
▪ For ERLQ011~016 and EBLQ+EDLQ011~016CA(3)V3+W1 outdoor units, the
power limitation functionality is NOT available. When these outdoor units are
used in a Smart Grid system, they will operate without power limitation. Electrical
heater assistance, however, will be disabled.
WARNING
Make sure to connect the electricity meter in the correct direction, so that it
measures the total energy injected INTO the grid.
INFORMATION
▪ For dynamic power limitation to be possible, a single connection point to the grid
is required (one connection point for the photovoltaic system AND the domestic
appliances). To function properly, the Smart Grid algorithm requires the net sum
of generated AND consumed energy. The algorithm will NOT work when there
are separate meters for generated energy and consumed energy.
▪ Since dynamic power limitation is performed based on electricity meter input,
you do NOT have to set the power limitation value in the configuration web
interface.
7.2 Operation modes
Operation modes:
▪ Heating and cooling (air to air).
▪ Fan only operation (air to air).
This operation manual offers a non-exhaustive overview of the main functions of
the system.
For more information about the user interface, see the operation manual of the
installed user interface.
7.2.1 "Normal operation/Free running" mode
In the "Normal operation"/"Free running" operation mode, the indoor unit
operates as normal, according to its owner's settings and schedules. No Smart Grid
functionalities are enabled.
7.2.2 "Recommended ON" mode
In the "Recommended ON" operation mode, the heat pump system makes use of
solar/grid power (when it is available, as measured by the solar inverter/energy
management system) to produce domestic hot water and/or heat up or cool down
the space. The amount of solar/grid power that is used for buffering depends on
the domestic hot water tank and/or the room temperature. To align solar/grid
capacity and the power consumption by the heat pump system, the power
consumption of the indoor unit is limited either statically (by a fixed value set in the
