8 | Electrical installation
Installer reference guide
49
AZAS100~140MUV/Y
Sky Air Active-series
4P743509-1B – 2024.05
8.1.3 About electrical compliance
AZAS100~140MUV
Equipment complying with EN/IEC 61000‑3‑12 (European/International Technical
Standard setting the limits for harmonic currents produced by equipment
connected to public low-voltage systems with input current >16A and ≤75A per
phase.).
AZAS100~140MUY
Equipment complying with EN/IEC 61000‑3‑2 (European/International Technical
Standard setting the limits for harmonic currents produced by equipment
connected to public low-voltage systems with input current ≤16A per phase.).
8.2 Connections to the outdoor unit
8.2.1 Specifications of standard wiring components
Component AZAS100~140MUV AZAS100~140MUY
100 125 140 100 125+140
Power supply cable MCA
(a)
21.8A 28.3A 27.6A 14.6A 15.1A
Voltage range 220~240V 380~415V
Phase 1~ 3N~
Frequency 50Hz
Wire sizes Must comply with national wiring regulation
3-core cable 5-core cable
Wire size based on the current, but not less than:
4.0 mm
2
2.5 mm
2
Interconnection cable
(indoor ↔ outdoor)
Voltage 220-240V
Wire size Only use harmonised wire providing double insulation and
suitable for applicable voltage.
4-core cable
Minimum 2.5mm
2
Recommended field fuse 25A 32A 16A
Earth leakage circuit breaker / residual current
device
Must comply with national wiring regulation
(a)
MCA=Minimum circuit ampacity. Stated values are maximum values (see electrical data of combination with indoor units for exact
values).
Note: Supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed
flexible cord (code designation 60245 IEC 57).
