2 Specific installer safety instructions
Installation manual
6
EPSK06~14A
Daikin Altherma 4 H
4P773384-1 – 2024.08
2 Specific installer safety
instructions
Always observe the following safety instructions and regulations.
!!Read this before you start the installation!!
Training
▪ Before you start the installation, follow the Daikin L1 Safety
Training (see QR code). Without this training you cannot unlock
the outdoor unit (via the e-Care app and the user interface of the
indoor unit) and you cannot start operation of the unit.
Personal safety protection tools
▪ Make sure suitable tooling and work materials are available.
Installation location
▪ Respect the installation location guidelines.
▪ Respect the protective zone around the outdoor unit (no ignition
sources).
▪ Take a picture of the installed outdoor unit and its environment.
You will have to upload it during the unlocking procedure of the
outdoor unit.
Hand-over to the user
▪ Explain to the user how to safely use the R290 heat pump.
▪ Explain to the user to NOT turn OFF the circuit breakers to the
units so that the protection remains activated.
Installation site (see "4.1Preparing the installation site"[48])
WARNING
Follow the "service space" and "protective zone"
dimensions in this manual to install the unit correctly. See
"4.1.1 Installation site requirements of the outdoor
unit"[48].
WARNING
The appliance shall be stored in a room without ignition
sources (neither permanent ignition sources nor ignition
sources for a short period of time) (example: open flames,
an operating gas appliance or an operating electric heater).
WARNING
The appliance shall be installed in an area without ignition
sources (neither permanent ignition sources nor ignition
sources for a short period of time) (example: open flames,
an operating gas appliance or an operating electric heater).
WARNING
Make sure installation, servicing, maintenance and repair
comply with instructions from Daikin and with applicable
legislation (for example national gas regulation) and are
executed ONLY by authorised persons.
Mounting the outdoor unit (see "4.2Mounting the outdoor
unit"[49])
WARNING
Fixing method of the outdoor unit MUST be in accordance
with the instructions from this manual. See "4.2 Mounting
the outdoor unit"[49].
CAUTION
To avoid injury, do NOT touch the air inlet or aluminium
fins of the unit.
Opening and closing the units (see "4.2Mounting the outdoor
unit"[49])
DANGER: RISK OF ELECTROCUTION
Do NOT leave the unit unattended when the service cover
is removed.
DANGER: RISK OF BURNING/SCALDING
Piping installation (see "5Piping installation"[411])
WARNING
Field piping MUST be in accordance with the instructions
from this manual. See "5Piping installation"[411].
WARNING
Adding anti-freeze solutions (e.g. glycol) to the water is
NOT allowed.
Electrical installation (see "6Electrical installation"[412])
DANGER: RISK OF ELECTROCUTION
WARNING
Electrical wiring MUST be in accordance with the
instructions from this manual. See "6 Electrical
installation"[412].
WARNING
▪ All wiring MUST be performed by an authorised
electrician and MUST comply with the national wiring
regulation.
▪ Make electrical connections to the fixed wiring.
▪ All components procured on-site and all electrical
construction MUST comply with the applicable
legislation.
WARNING
ALWAYS use multicore cable for power supply cables.
WARNING
If the supply cord is damaged, it MUST be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
CAUTION
Do NOT push or place redundant cable length into the unit.
WARNING
▪ If the power supply has a missing or wrong N-phase,
equipment might break down.
▪ Establish proper earthing. Do NOT earth the unit to a
utility pipe, surge absorber, or telephone earth.
Incomplete earthing may cause electrical shocks.
▪ Install the required fuses or circuit breakers. See
"6.2 Specifications of standard wiring
components"[412].
▪ Secure the electrical wiring with cable ties so that the
cables do NOT come in contact with sharp edges or
piping, particularly on the high-pressure side.
▪ Do NOT use taped wires, extension cords, or
connections from a star system. They can cause
overheating, electrical shocks or fire.
▪ Do NOT install a phase advancing capacitor, because
this unit is equipped with an inverter. A phase
advancing capacitor will reduce performance and may
cause accidents.
