6 | Unit installation

Installer reference guide

2MXM-A8, 3MXM-A8, 4MXM-A8, 5MXM-A8

R32 Split series

4P766272-5C – 2025.05

6 Unit installation

WARNING

Installation shall be done by an installer, the choice of materials and installation shall

comply with the applicable legislation. In Europe, EN378 is the applicable standard.

In this chapter

6.1 Preparing the installation site ................................................................................................................................................ 24

6.1.1 Installation site requirements of the outdoor unit ............................................................................................... 25

6.1.2 Additional installation site requirements of the outdoor unit in cold climates ................................................... 27

6.2 Opening the unit..................................................................................................................................................................... 28

6.2.1 About opening the unit.......................................................................................................................................... 28

6.2.2 To open the outdoor unit ...................................................................................................................................... 28

6.3 Mounting the outdoor unit .................................................................................................................................................... 28

6.3.1 About mounting the outdoor unit......................................................................................................................... 28

6.3.2 Precautions when mounting the outdoor unit...................................................................................................... 29

6.3.3 To provide the installation structure..................................................................................................................... 29

6.3.4 To install the outdoor unit ..................................................................................................................................... 30

6.3.5 To provide drainage ............................................................................................................................................... 30

6.3.6 To prevent the outdoor unit from falling over...................................................................................................... 31

6.1 Preparing the installation site

WARNING

The appliance shall be stored so as to prevent mechanical damage and in a well-

ventilated room without continuously operating ignition sources (e.g. open flames,

an operating gas appliance, or an operating electric heater). The room size shall be as

specified in the General safety precaution.

Choose an installation location with sufficient space to transport the unit in and

out of the site.

Do NOT install the unit in places often used as work place. In case of construction

works (e.g. grinding works) where a lot of dust is created, the unit MUST be

covered.

CAUTION

▪ Check if the installation location can support the unit's weight. Poor installation is

hazardous. It can also cause vibrations or unusual operating noise.

▪ Provide sufficient service space.

▪ Do NOT install the unit so that it is in contact with a ceiling or a wall, as this may

cause vibrations.

▪ Choose a location where the operation noise or the hot/cold air discharged from

the unit will not disturb anyone and the location is selected according the

applicable legislation.

▪ Provide sufficient space around the unit for servicing and air circulation.

▪ Avoid areas where flammable gas or product might leak.

▪ Install units, power cables and communication wiring at least 3 m away from

televisions or radios to prevent interference. Depending on the radio waves, a

distance of 3m may not be sufficient.
