Operation Manual
112
Click , and you can drag any corner of the box to adjust the size of the area, and
press the left mouse button and move the box to adjust the position.
Step 5 D
raw multiple people counting areas in Detection Area as needed.
1) Click Add Rule to add statistical areas.
2) Set the name of Area and People Number to Trigger Alarm.
When the number of the people in the area exceeds the configured threshold, the
alarm will be triggered, and the system will perform the linkage actions. The
people number to trigger alarm is 20 by default.
3) Click at the right side of the image, draw people counting areas in the
detection area, and then right-click to finish the drawing.
4) Repeat the above steps to add more people counting areas.
ā
Click , and then press and hold the left mouse button to draw a rectangle,
and then pixel size is displayed.
ā
Click to delete the drawn detection or people counting areas.
Step 6 C
onfigure parameters.
Table 8-1 Description of crowd map parameters
Parameter Description
Global
Click next to Global and set the crowd density threshold.
The system detects crowd distribution in the global area. When
the crowd density exceeds the configured threshold, the system
performs alarm linkages.
Crowd Density
Step 7 Set arming periods and alarm linkage action. For details, see "6.5.1.2 Alarm Linkage".
Click + Event Linkage to set the linkage action.
Step 8 C
lick Apply.
To view alarm information on the alarm subscription tab, you need to subscribe
relevant alarm event. For details, see "6.5.1.3.2 Subscribing Alarm Information".
Result
Click on the Live page to view the crowd distribution map.
Figure 8-3 Crowd map (1)
Double-click the rendering area at the lower-right corner in the image to view crowd
distribution in the area.
