DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
49
Location
LED
Color
Status
Description
Off
Light off
Power off
Console
Green
Light on (Solid)
RJ45 console port is active
Off
Light off
Console off
Fan Err
Red
Light on (Solid)
Fan fail
Off
Light off
Operating normally
RPS
Green
Light on (Solid)
RPS in use
Light off
RPS off
USB
Green
Light on (Solid)
USB plugged in
Light blinking
Busy reading/writing
Off
Light off
No USB plugged in
Stacking ID
(7-segment LED)
Green
Light on (1-9)
Stacking number displayed
Light on (H)
Stacking Master
Light on (h)
Stacking Backup Master
Light on (E)
System self-test error
Light on (G)
Safeguard Engine in exhausted mode
LED Per
2.5 Gbps Port
Link/Act/Speed
Green
Light on (Solid)
When there is a connection (or link) to a
2.5 Gbps Ethernet device on any of the
ports
Light blinking
When there is reception or transmission
of data occurring at 2.5 Gbps
Amber
Light on (Solid)
When there is a connection (or link) to a
100/1000 Mbps Ethernet device on any of
the ports
Light blinking
When there is reception or transmission
of data occurring at 100/1000 Mbps
Off
Light off
Link down or no link
PSE (for DMS-
3130-30PS only)
Green
Light on (Solid)
Supplying power to Powered Devices
Amber
Light on (Solid)
Error condition
Off
Light off
Link down or no link
LED Per
5 Gbps Port
(for DMS-3130-
30PS only)
Link/Act/Speed
Green
Light on (Solid)
When there is a connection (or link) to a
2.5 or 5 Gbps Ethernet device on any of
the ports
Light blinking
When there is reception or transmission
of data occurring at 2.5 or 5 Gbps
Amber
Light on (Solid)
When there is a connection (or link) to a
100/1000 Mbps Ethernet device on any of
the ports
Light blinking
When there is reception or transmission
of data occurring at 100/1000 Mbps
Off
Light off
Link down or no link
PSE
Green
Light on (Solid)
Supplying power to Powered Devices.
Amber
Light on (Solid)
Error condition
Off
Light off
Link down or no link
LED Per
10 Gbps Port
Link/Act/Speed
Green
Light on (Solid)
When there is a connection (or link) to a
2.5/5/10 Gbps Ethernet device on any of
the ports
