DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
48
Feature
Description
USB Slot
Supports a USB 2.0 Type-A flash drive with a maximum current of 1 A.
This slot only supports FAT16 and FAT32 file system architectures.
Power Consumption
DMS-3130-30TS: 74.26W (Max.), 43.84W (Standby)
DMS-3130-30PS: 1211.5W (PoE on)/88.9W (PoE off), 58.3W (Standby)
Temperature
Operating: 0 °C to 50 °C (32 °F to 122 °F)
Storage: -40 °C to 70 °C (-40 °F to 158 °F)
Humidity
Operating: 10 % to 90 % RH (non-condensing)
Storage: 5 % to 90 % RH (non-condensing)
Heat Dissipation
DMS-3130-30TS: 253,38 BTU/Hr. (Max.)
DMS-3130-30PS: 4137.73 BTU/Hr. (Max.)
Dimensions
DMS-3130-30TS: 440 mm (W) x 250 mm (D) x 44 mm (H), 19-inch, 1 U
Rack-mount size
DMS-3130-30PS: 440 mm (W) x 470 mm (D) x 44 mm (H), 19-inch, 1 U
Rack-mount size
Weight
DMS-3130-30TS: 3.63Kg (8 lbs)
DMS-3130-30PS: 6.54Kg (14.41 lbs)
MTBF
DMS-3130-30TS: 270,340.81 Hours
DMS-3130-30PS: 277,222.63 Hours
EMC Certifications
CE Class A, FCC Class A, VCCI Class A, RCM, BSMI
Safety Certifications
UL/cUL, CB, BSMI
Performance
Feature
Description
Transmission Method
Store-and-forward
Packet Buffer
DMS-3130-30TS: 4 MBytes per device
DMS-3130-30PS: 4 MBytes per device
Jumbo Frame Size
12K Bytes (12288 Bytes)
Switching Capacity
DMS-3130-30TS: 360 Gbps
DMS-3130-30PS: 400 Gbps
Maximum Packet Forwarding Rate
DMS-3130-30TS: 268 Mpps
DMS-3130-30PS: 298 Mpps
Priority Queues
8 Priority Queues per port
MAC Address Table
Supports 32K (32,768) MAC addresses
IP Routing Tables
IPv4 and IPv6: Max.1024 entries
Virtual Stacking / Clustering
Supports D-Link Single IP Management version 2.01
Manages up to 32 devices in a virtual stack with a single IP address
LED Indicators
Location
LED
Color
Status
Description
Per Device
Power
Green
Light on (Solid)
Power on
