14
FACTORY SETTING
2ND LEVEL 3RD LEVEL
Are you sure? NO
Yes
1) Factory Setting: Selecting YES will reset the unit’s settings back to
their factory defaults.
Note: The transceiver mode will not be reset.
6.6 Basic AV Extension
6.6.1 Point-to-Point Conguration
The most basic extension configuration available is a point-to-point
system with a single unit in Transmitter Mode connected directly to
a single unit in Receiver Mode. In this configuration the HDMI input
on the Transmitter is transmitted to the connected Receiver without
modification to the audio or video format. The analogue stereo audio port
on the transmitter functions as an input and transfers audio directly to
the analogue stereo audio port on the receiver for output. The LAN, USB,
RS-232 and IR ports form direct connections between transmitter and
receiver.
Fiber Cable
Note: This configuration does not use or require an external control center
such as the IP Master Controller to function. No audio insertion/extraction is
performed in this configuration.
6.7 Advanced AV Extension
6.7.1 IP Master Controller
The IP Master Controller is a hardware solution designed to provide a
unified and easy method to access and control all of the transmitters and
receivers in a system. It provides a user-friendly, and operating system
agnostic, web-based interface allowing easy control over all of the most
