6
5
AUDIO PORTS:
OUT Port: Connect to powered speakers or an amplier for stereo
analogue audio output.
IN Port: Connect to the stereo analogue output of a device such as
a CD player or PC.
Note: When transceivers are connected directly in a Point-to-Point
conguration, audio is routed directly from the IN Ports to the opposite
end’s OUT Ports. Free routing can only be congured by use of the
optional IP Master Controller or control software.
6
IR PORTS:
OUT Port: Connect to an IR Blaster to broadcast IR signals from a
connected transceiver to devices within direct line-of sight of the IR
Blaster.
IN Port: Connect to an IR Extender to receive IR control signals
and extend them to devices connected to a connected transceiver.
Ensure that the remote being used is within direct line-of-sight of
the IR Extender.
Note: Currently, only 38KHz IR signal extension is supported.
7
RS-232 3-pin Terminal Block: Connect directly to a PC, laptop or
serial controllable device with a 3-pin adapter cable to extend the RS-
232 signal between transceivers.
8
LAN Port: Connect to an Ethernet supporting device or to your local
network as appropriate to extend the network between transceivers.
9
USB/SERVICE (Mini-B) Port: Connect directly to a standard USB host
such as a PC or laptop to extend their USB functionality to all currently
connected/routed USB devices.
Note: This port is only active when “USB Control Mode” is set to “Device”.
Only one of the two connected transceivers should be set as a USB Device
to avoid conicts.
10
DC 12V Port: Plug the 12V DC power adapter into this port and
connect it to an AC wall outlet for power.
