8
6.6.1 Monitor & Control Tab
This tab provides easy to use drag-and-drop control over all basic routing
functionality of the transmitters and receivers that have been detected
within the local network. In all sections, except for the Video section,
transmitters are represented by the source icon ( ) and receivers are
represented by the display icon ( ). Each of this tab’s sections control
the routing of a dierent type of interface that can be found on most
compatible transmitters, receivers or transceivers. These interfaces are:
Video routing, Video Wall routing, Multiview selection, HDMI Audio
routing, Analogue Audio routing, USB routing, IR routing, RS-232 routing,
and Macro activation. This tab’s controls are available even when a user
is not logged in, providing basic control over routing without exposing
system critical conguration areas.
Note: Units that were previously a part of the system, but are not currently
detected will still be displayed, however they will have a disconnected icon (
) and cannot be used for routing.
1) Video Routing: Provides drag-and-drop control over the video
routing between all detected transmitters and receivers. Each
transmitter and receiver box will display a small, low framerate, video
thumbnail to indicate what video is currently active.
Note: Certain operational modes (multiview, video wall) and some
transmitters and receivers do not support the video thumbnail feature.
Video Transmitter: This section provides drag-and-drop buttons
for all transmitters detected by the system as well as a multi-option
button target to stop video streams from being transmitted.
