28
“Download” button. Depending on your browser settings you will
either be asked where to save the downloaded file, or the file will
be transferred to the default download location on your PC.
Edit Name: Click the “Edit Name” button to open a window that
allows changing the name of the User EDID. Click the “Save” button
within the window to confirm the change.
2) Output EDID:
Download: To save the EDID from the connected display to your
local PC, select the sink from the dropdown list then press the
“Download” button. Depending on your browser settings you will
either be asked where to save the downloaded file, or the file will
be transferred directly to the default download location on your PC.
3) Input EDID: This section provides controls for assigning a new EDID
to one, or all inputs within the system.
Appoint/All: Selecting “All” will allow the assignment of a single
EDID to all inputs simultaneously. Selecting “Appoint” allows for a
different EDID to be assigned to each HDMI input.
EDID Selection: Click on the input on the left to open the EDID
Table List window. Select the new EDID source to use and the
change will occur immediately across all selected inputs.
Note: In most cases, assigning a new EDID to an input will cause the
affected inputs to briefly blink out while the source adapts to the new
information.
This unit provides the following 3 default EDIDs:
Unit’s default EDIDs
FHD/PCM/2CH 1920×1080p@60Hz (4.95Gbps) & 8-bit colour,
LPCM 2.0
UHD/PCM/2CH 3840×2160p@30Hz (10.2Gbps) & Deep Colour
(8/10/12-bit), LPCM 2.0
UHD+/PCM/2CH 3840×2160p@60Hz (18Gbps) & Deep Colour
(8/10/12-bit), LPCM 2.0
Note: In some rare cases it is possible for custom or external EDIDs to cause
compatibility issues with certain sources. If this happens, it is recommended
to switch to one of the 3 default EDIDs for maximum compatibility.
