39
6.4.6 Input EDID Tab
This unit provides the option of three standard EDIDs, two sink source
EDIDs and four user uploaded EDIDs that can be assigned to all inputs at
the same time, or to each input independently.
Note: In most cases, assigning a new EDID to an input will cause the affected
input to briefly blink out while the source adapts to the new information.
1) EDID Mode: Use the dropdown to select how to assign EDIDs to the
unit’s inputs. Selecting “Independent” allows for a dierent EDID to be
assigned to each input, selecting “All” allows for a single EDID to be
assigned to all inputs.
2) All EDID: Select the EDID to assign to all inputs.
Note: Only available in “All” EDID Mode.
3) IN 2~3 EDID: Select the EDID to assign to the specied input.
Note: Only available in “Appoint” EDID Mode.
This unit provides the following 3 default EDIDs:
Unit’s default EDIDs
FHD 2CH 1920×1080p@60Hz (4.95Gbps) & 8-bit
color, LPCM 2.0
4K UHD 2CH 3840×2160p@30Hz (10.2Gbps) & Deep
Color (8/10/12-bit), LPCM 2.0
4K UHD
+
2CH 3840×2160p@60Hz (18Gbps) & Deep
Color (8/10/12-bit), LPCM 2.0
Note: In some rare cases it is possible for custom or external EDIDs to
