6.3.2 IR Remote (Assignable Buttons)
Standard Mode
The function of the buttons on the bottom half of the
IR remote are user defined within the WebGUI. They
are used to tell the unit to transmit IR commands to
the source device currently being viewed in the user’s
current Zone location.
For example, if the user is watching input 3 while in
Zone A, then pressing any of these buttons will send
the associated user-defined commands to the device
connected to input 3 via the IR Blaster connected to
IR output 3. If the user then moves to Zone B, which
is watching input 2, and presses the same buttons, the unit will send
commands associated with input 2 via the IR Blaster connected to IR
output 2.
(1) Zone A Mirrored Outputs (HDBaseT)
Source 3
Source 3
RS-232 OUT
ISP
SYNC
PWR
STD
UPDATE
LINKHQ/STD
1 2 3
4 5
6
7 8
9
0
Adv.
1234 1234
ZONE
BAARC
IR SERVICEZONE AZONE BAUDIO SELECT MUTE Vol –Vol +POWER
MA-421
Source 1 Source 2 Source 3 Source 4
HDBaseT
Output
UHDTV
IR Control of
Input 1~4
