5
8
LOOPBACK/LINK Button: This button controls the following
functions:
Loopback: Press this button momentarily to toggle the VGA
loopback function on and o, allowing you to locally monitor
non-HDCP HDMI sources (1080p or below) for troubleshooting
purposes.
Video Link: Press and hold the button for 3 seconds to enable or
disable the streaming link with the currently routed receiver. When
the link is disabled, and the receiver is connected to a display, it will
show the system’s current IP and rmware information.
Reset to Factory Defaults: Press and hold this button when
powering the unit on until both the POWER and LINK lights are
blinking. Once both lights are blinking you can reboot the unit
and all settings will be returned to the factory defaults (Including
resetting the IP mode to auto, broadcast channel to 0, and the
streaming mode to multicast). A new IP address will be assigned
automatically within the 169.254.xxx.xxx address range.
9
MODE/Anti-DITHER Button: This button controls the following
functions:
Video Mode: Press this button momentarily to toggle the video
data streaming method between “Graphic” and “Video” modes.
“Graphic” mode is optimised for high-detail static displays and
“Video” mode is optimised for full motion video.
Anti-Dither: Press and hold this button for 3 seconds to switch
between the three “Anti-Dither” modes (1-bit, 2-bit, and o).
Note: Certain graphics cards use dithering to emulate a larger colour
palette, but dithering causes difficulty for maintaining low-bandwidth
during real-time video compression. These modes are designed to
remove the dithering prior to compression and transmission of the
signal. The Anti-Dither feature is set to “off” by default. If the source is
not using dithering, please leave this feature disabled as it may cause a
blocking effect with non-dithered content.
10
ISP Pinhole: This is for factory use only.
11
RESET Pinhole: Press this recessed button to reset the unit’s power
supply and reboot the unit.
Note: Settings will not be reset.
12
VGA LOOPBACK Port: Connect to an analogue VGA monitor to locally
view the connected HDMI (non-HDCP, 1080p or lower) source.
