15
long as the same measurement units are used to measure each display
and the displays are still arranged in a normal rectangular layout with
corners meeting at the same place.
Apply To: Select which unit(s) to send updated settings to when
“Apply” is pressed.
- Selecting “All” will direct updates to the video wall Bezel settings
of all units in the current video wall group (transmitter and
receivers).
- Selecting an IP address from the “Clients” list will direct updates
to the video wall settings of the receiver with that IP address.
2) Wall Size and Position Layout: This section of the Video Wall tab is
used to dene the number of displays used in the video wall as well
as the location of the specic display within the video wall. A typical
video wall consists of an equal number of horizontal and vertical
monitors (for example: 2×2 or 3×3), however it is possible to create
video walls using this system with a wider variety of dimensions as
long as the end result is still a rectangle (for example: 5×1 or 2×3).
Both horizontal and vertical dimensions are limited to a maximum of
16 displays.
Vertical Monitor Count: Dene the number of displays in the
video wall, measured vertically. (Maximum is 16 displays)
Horizontal Monitor Count: Dene the number of displays in the
video wall, measured horizontally. (Maximum is 16 displays)
Row Position: Set the vertical location of the currently controlled
display. (Counts top to bottom, from 0 to 15)
Column Position: Set the horizontal location of the currently
controlled display. (Counts left to right, from 0 to 15)
