14
When saving changes on the Video Wall tab, remember to select the
appropriate “Apply To:” target unit before pressing the “Apply” button. On
transmitters, settings may only be applied to remote receivers within the
same video wall group. Select the IP address of the receiver (Client) you
want to apply changes to from the “Apply To:” drop down or select “All” to
send the changes to all receivers in the group.
Note: Video walls can only be generated when all associated units are in
multicast mode.
1) Bezel and Gap Compensation: This section of the Video Wall tab
is used to dene the physical dimensions of each display being
used in the video wall. Accurate measurements are needed of the
monitor’s outer frame (OW, OH) and the video screen (VW, VH). The
measurements may be made using any unit format (inches, mm, cm,
etc.) as long as ALL measurements in the same wall are made using
the exact same units and the numbers are integers.
OW (Outer Width): This is the horizontal measurement of the
display’s outer case.
OH (Outer Height): This is the vertical measurement of the display’s
outer case.
VW (Video Width): This is the horizontal measurement of the
display’s video screen.
VH (Video Height): This is the vertical measurement of the display’s
video screen.
Note: Typically all monitors in a video wall are identical and have the
same dimensions, but it is possible to use dierently sized displays as
