44
2) Sink EDID Download: To save the EDID from one of the connected
displays to your local PC, select the appropriate sink from the
dropdown list then press the “Download” button. Depending on
your browser settings you will either be asked where to save the
downloaded file, or the file will be transferred directly to the default
download location on your PC.
3) Set EDID Input Content: This section provides controls for assigning
EDID to the unit’s inputs. Click on the preferred input(s) on the left
and then select the EDID on the right and the change will occur
immediately. Multiple inputs can be selected at once if desired.
Note: In most cases, assigning a new EDID to an input will cause the
affected input to briefly blink out while the source adapts to the new
information.
This unit provides the following 7 default EDIDs:
Unit’s Default EDIDs
FHD 2CH 1920×1080p@60Hz (4.95Gbps) & 8-bit colour, LPCM
2.0
FHD MCH 1920×1080p@60Hz (4.95Gbps) & 8-bit colour, LPCM
7.1 & Bitstream
UHD 2CH 3840×2160p@30Hz (10.2Gbps) & Deep Colour
(8/10/12-bit), LPCM 2.0
UHD MCH 3840×2160p@30Hz (10.2Gbps) & Deep Colour
(8/10/12-bit), LPCM 7.1 & Bitstream
UHD+ 2CH 3840×2160p@60Hz (18Gbps) & Deep Colour
(8/10/12-bit), LPCM 2.0
UHD+ MCH 3840×2160p@60Hz (18Gbps) & Deep Colour
(8/10/12-bit), LPCM 7.1 & Bitstream
VGA 1920×1080p@60Hz (148MHz) & 8-bit colour
Note: In some rare cases it is possible for custom or external EDIDs to cause
compatibility issues with certain sources. If this happens, it is recommended
to switch to one of the 7 default EDIDs for maximum compatibility.
