15
6) OSD Info Timeout and Offset: The OSD Info timeout value (in
seconds) and horizontal and vertical position may be set here.
7) Image Overlay Display: Enables or disables the custom image
overlay feature.
Note: Enabling OSD Info will automatically disable the Image Overlay.
8) Image Overlay Update: To upload a custom overlay image, insert
a USB thumb drive, with a valid graphics file named “LOGO.BMP”
(1920×1080 max resolution, 8-bit colour) in the root directory, into the
unit’s USB service port then click the “Update” button.
9) Image Overlay Positioning: Set the horizontal and vertical position
of the upper-left corner of the custom overlay image.
The “Image” tab in Rotation Mode provides control over the automatic
360° rotation mode as well as the 45° fixed screen rotation mode. To
return these settings to their factory defaults, click on the “Default”
button.
1) Automatic 360° Rotation Mode: Allows activation of the automatic
360° rotation mode. Select the speed and direction from the
dropdown menu (slow counter-clockwise, slow clockwise, fast
counter-clockwise, fast clockwise, stop).
2) Fixed 45° Rotation Angle Mode: Allows rotating the source image
to fixed, 45°, angles. Select the preferred rotation angle from the
dropdown menu.
