14
IR Learn: To learn an IR command, rst make sure the included IR
Extender is connected to the unit’s IR IN port, then press the “IR
Learn” button. After doing this a notice will appear in the WebGUI
to send the IR signal within 5 seconds. Point the remote control at
the IR receiver and press the button that contains the command
you wish to learn. A command string will appear in the text entry
window containing the information captured from the IR remote.
Command Data: The command data to send is entered in this text
box. The types of commands available and the interface to use with
them are detailed below.
Note: Except where explicitly mentioned, the “STD” format checkbox
should always be checked.
- System Commands (SysCMD Interface): Commands to control
functions of the unit directly using the Telnet functions detailed
in section 6.8.
Note: Care must be taken when sending system commands, as they
can impact the functionality of the unit itself.
- Telnet or Serial Commands (Telnet & COM Interfaces): Simply
enter the plain ASCII text of the command in the space provided.
Special control characters that can’t normally be typed should be
entered using their ASCII hex octet pair value preceded by the “\
x” escape sequence. For example, a carriage return and linefeed
would be entered as: “\x0d\x0a”.
- IR Commands (IR Interface): Typically this data is automatically
lled in by using the IR Learning function, however an IR code
may also be manually entered if necessary.
Note: If the IR code is in “Pronto” format the “RAW HEX” checkbox
must be checked.
- Relay Commands (Relay Interface): Commands to control the
state of each relay port. The port to control is assigned during the
creation of each individual macro.
CLOSE: Closes the circuit of the assigned relay port.
OPEN: Opens the circuit of the assigned relay port.
TOGGLE: Toggles the state of the assigned relay port.
2) Delete Command: To clear the contents of a command, click on the
“Remove” button. The contents will be removed immediately.
Note: There is no “Undo” function! Please use caution when using the
“Remove” button!
