AUDIO PORTS:
OUT Port: Connect to powered speakers or an amplifier for stereo
analogue audio output.
IN Port: Connect to the stereo analogue output of a device such as
a CD player or PC.
Note: Audio is routed directly from the IN Port to the opposite
transceiver’s OUT Port.
6
IR PORTS:
OUT Port: Connect to an IR Blaster to broadcast IR signals from a
connected transceiver to devices within direct line-of sight of the IR
Blaster.
IN Port: Connect to an IR Extender to receive IR control signals
and extend them to devices connected to a connected transceiver.
Ensure that the remote being used is within direct line-of-sight of
the IR Extender.
Note: Currently, only 38KHz IR signal extension is supported.
7
RS-232 3-pin Terminal Block: Connect directly to a PC, laptop or
serial controllable device with a 3-pin adapter cable to extend the RS-
232 signal between transceivers.
8
LAN Port: Connect to an Ethernet supporting device or to your local
network as appropriate to extend the network between transceivers.
9
USB/SERVICE (Mini-B) Port: Connect directly to a standard USB host
such as a PC or laptop to extend their USB functionality to all currently
connected/routed USB devices.
Note: This port is only active when “USB Control Mode” is set to “Device”.
Only one of the two connected transceivers should be set as a USB Device
to avoid conflicts.
10
DC 12V Port: Plug the 12V DC power adapter into this port and
connect it to an AC wall outlet for power.
