6Curtis Instruments enGage
®
VI Manual
2.0 INSTALLATION
2.1 CONNECTORS
Cased / Enclosed Products (Model 3601T):
• Standard connector series is sealed Deutsch DTM.
• Optional video input uses connector J3 for input signals.
Module Products (Model 3601P):
• Standard connector series is AMP MATE-N-LOK.
• Pushbutton signals are available on connector J4.
• Optional video input uses connector J3 for input signals.
The Curtis enGage
®
VI is available with extensive I/O & CAN communications or as a CANbus
display unit, “CAN only” design (no I/O).
Models designated as “CAN only” do not offer access to I/O pins and have only one connector
“J1” (no other connectors required).
I/O connections for module and cased models are detailed in Tables 6 and 7, on the
following pages.
Mating Connectors, Cased / Enclosed Product Model 3601T
• Deutsch DTM series mating connectors for J1 through J4 are detailed in Table 5.
• Deutsch Wedge Lock, 1 per connector, part number: WM-12S (Curtis p/n 12690CA29)
• Deutsch pin, up to 12 per connector, part number 0462-201-20141 (Curtis p/n
12690FC59)
CAUTION: Video connector not sealed unless mating connector attached!!
Table 5 Cased / Enclosed Product Model 3601T Deutsch Mating Connector
NOTE: Housing p/n only, see Page 4 for Wedge Lock and Pin p/n’s.
Connector
Mating Connector
Maximum Operating
Voltage (VDC)
Deutsch p/n Curtis p/n
J1 DTM06-12SA 12690FH140
J2 DTM06-12SB 12690FH141
J3 DTM06-12SC 12690FH142
