6 — PROGRAMMABLE PARAMETERS

Curtis Electronic Code Switch Module (ECS) – June 2022 Return to TOC

pg. 24

CAN Interface Menu

e following table describes the parameters on the CAN Interface menu.

APPLICATION SETUP MENU — CAN INTERFACE MENU

PARAMETER

CAN INDEX

VALUES

RAW VALUES

DATA SIZE

READ/WRITE

ACCESS LEVEL

DEFAULT VALUE DESCRIPTION

Baud Rate [PCF]

0x2001:01

–1 to +4

8-bit

RW

OEM Dealer

0

Species the CAN baud rate:

–1 = 100 Kbps

0 = 125 Kbps

1 = 250 Kbps

2 = 500 Kbps

3 = 800 Kbps

4 = 1 Mbps

Node ID [PCF]

0x2000:01

1–7Fh

8-bit

RW

OEM Dealer

46h

Species the ECS’s node ID.

Note: Node ID 127 is reserved for Curtis

programming devices.

Heartbeat Rate

0x1017:00

16–200ms

4–50

16-bit

RW

OEM Factory

100ms

Specifies the cyclic rate of the ECS's

heartbeat messages.

Auto Operation

0x32BC:00

Off/On

0–1

8-bit

RW

OEM Dealer

Off

Species the ECS’s NMT state after it has

powered up:

On = Operational

Off = Pre-operational

CAN NMT State

0x32A4:00

0–127

8-bit

RO

Field Basic

N/A

Indicates the ECS’s NMT state:

0 = Initialization

4 = Stopped

5 = Operational

127 = Pre-operational

e CAN Interface menu contains the RPDO Setups and TPDO Setups menus. e PDO Setups

menus contain the RPDO Mapping and TPDO Mapping menus, which specify the objects for which

the PDOs transmit and receive data.
