6 — PROGRAMMABLE PARAMETERS

pg. 19

Return to TOC Curtis Electronic Code Switch Module (ECS) – June 2022

LOGON USER SETUP MENU

e following table describes the Logon User Setup menu. e parameters let the logged-on user

create or change the user’s PIN code, RFID tag, and user name code.

e Logon User Setup Menu is visible only when the supervisor is logged on to manage users or the

vehicle operator is logged on to manage the user’s credentials. In addition, the menu’s parameters

can be accessed through the CANbus only if the supervisor or vehicle operator is logged on.

LOGON USER SETUP MENU

PARAMETER

CAN INDEX

VALUES

RAW VALUES

DATA SIZE

READ/WRITE ACCESS LEVEL DESCRIPTION

New PIN Code

0x3828:00

0–999999999

32-bit

Field Basic Indicates a new PIN code for the logged-on user.

Specify 9 as a control word, followed by the PIN code.

For example, if the PIN code is 3579, specify 93579.

The new PIN code is activated by setting the Save

New PIN Code parameter to On.

Save New PIN Code

0x3829:00

Off/On

0–1

8-bit

Field Basic Activates the New PIN Code.

New RFID Tag

0x3827:00

Off/On

0–1

8-bit

Field Basic Adds or changes an RFID tag for the logged-on user.

To add the tag, set the parameter to On, then place

the tag in front of the ECS until the buzzer sounds

the Success sound.

Delete RFID Tag

0x382C:00

Off/On

0–1

8-bit

Field Basic Deletes the RFID tag of the logged-on user. To delete,

set the parameter to On.

New Name Code

0x382A:00

0–99999

32-bit

Field Basic Indicates a new user name code. Specify 9 as a control

word, followed by the user name code. For example, if

the user name code is 2468, specify 92468.

The new user name code is activated by setting the

Save New Name Code parameter to On

Save New Name Code

0x382B:00

Off/On

0–1

32-bit

Field Basic Activates the New Name Code.
