4 — INSTALLATION AND WIRING

Curtis Electronic Code Switch Module (ECS) – June 2022 Return to TOC

pg. 14

When the ECS commands the relay to close or open, the Relay State parameter indicates the

relay’s state:

• When the relay closes, the Relay State value changes in this order: 0, 1, 2, 3, 4, 5.

• When the relay opens, the Relay State value changes in this order: 5, 6, 8, 0.

e Relay Work Mode parameter species whether logging on or CAN commands engage the relay.

ere are also parameters for conguring the relay’s pull-in and holding voltages; see Relay Menu.

INTERLOCK

When the interlock state is o and the logo interval has expired, the ECS automatically logs the

user o. e logo interval is specied with the Logo Time parameter.

Note: e automatic logo can be disabled by setting Logo Time to 0.

e interlock signal can be controlled with either a switch, such as a seat switch, or RPDO1. e

Interlock Type parameter species the interlock signal’s source.

If the vehicle uses an interlock switch, connect the switch to pin 2. When a switch is used, the

interlock’s input voltage ranges from 0V to the B+ voltage. e interlock input is active high; the

interlock state is o when the interlock input’s voltage is below the voltage specied with the Interlock

High reshold parameter.

Note: For information on the interlock parameters, see Control Menu.

CANbus

To connect the ECS to the CANbus, connect CAN Low and CAN High to pins 5 and 6, respectively.

Use twisted-pair wiring to minimize the likelihood of picking up a voltage bias on only one signal.

Pin 1 provides access to an internal 120Ω terminating resistor. To enable the resistor, connect CAN

High (pin 6) to pin 1.

e ECS includes parameters for items such as the baud rate, heartbeat rate, node ID, and PDOs. For

more information, see CAN Interface Menu and CANopen Communications.

CALIBRATE THE ANTENNA

Aer the ECS is installed, calibrate the antenna so that the ECS automatically detects the best channel

for RFID recognition. You can calibrate with either of the following:

• e AM Base Calibration parameter.

• e keypad; see the Calibrate the Antenna section.
