3 — PROGRAMMER MENUS
pg. 11
Return to TOC Curtis 1355 CANopen Soft Starter Module Manual – September 2020
CONFIGURATION MENU
PARAMETER ALLOWABLE RANGE DESCRIPTION
Nominal Voltage 36.0 – 48.0 V Sets the nominal voltage.
24.0 – 36.0 V for the 1355-4X01.
36.0 – 48.0 V for the 1355-5X01.
Overvoltage
Warning Range
2.0 – 14.0 V Sets the allowed voltage above the nominal voltage. When the capacitor
bank voltage exceeds (Nominal Voltage + Overvoltage Warning Range), an
Overvoltage Warning message is issued on the CAN bus and programmer.
Undervoltage
Warning Range
2.0 – 14.0 V Sets the allowed voltage below the nominal voltage. When the capacitor bank
voltage drops below (Nominal Voltage – Undervoltage Warning Range), an
Undervoltage Warning message is issued on the CAN bus and programmer.
MAIN CONTACTOR MENU
PARAMETER ALLOWABLE RANGE DESCRIPTION
Contactor Control On / Off When programmed On, the 1355 controls the main contactor.
When programmed Off, the main contactor is controlled by an external device.
Pull In Voltage 0 – 100 % This parameter allows a high initial voltage when the main contactor rst
turns on, thus ensuring contactor closure. After 1 second, this peak voltage
drops to the contactor holding voltage.
Holding Voltage 0 – 100 % This parameter allows a reduced average voltage to be applied to the
contactor coil once it has closed. This parameter must be set high enough to
hold the contactor closed under all shock and vibration conditions the vehicle
will be subjected to.
Main Contactor
Current Limit
150 – 250 A This parameter limits the max current on the contactor. If the current is higher
than the programmed limit, the 1355 will limit the current of all the outputs so
as to bring the main contactor current below its allowed limit. Meanwhile, the
1355 will report the fault on the CAN bus and programmer.
