Curtis 1253 Manual, Rev. F
21
Blue Ox Rev. A, draft #1 [3 August 2007]
e throttle map operates within the window established by the rottle
Max Speed, rottle Deadband, and rottle Max parameters, as shown below
in Figure 17. rottle Max Speed defines the controller’s output range, while
rottle Deadband and rottle Max define the throttle’s active range. ese
three parameters, together with the rottle Map parameter, determine the
controller’s output response to throttle demand.
3 — PROGRAMMABLE PARAMETERS: Throttle Parameters
Fig. 11 rottle maps for
controller with maximum
speed set at 80%.
Fig. 12 Inuence of various
parameters on controller
output response to throttle
demand.
100908070605040302010 0
100
90
80
70
60
50
40
30
20
10
0
SPEED PARAMETER
80% Thrtl Max Speed
80%
60%
50%
40%
30%
20%
THROTTLE MAP
THROTTLE INPUT (percent of active range)
CONTROLLER OUTPUT (PWM percent)
THROTTLE
PARAMETERS
15% Deadband
90% Throttle Max
40% Throttle Map
SPEED PARAMETER
80% Thrtl Max Speed
80% Max Speed
40% Throttle Map
(32% output at
half throttle)
15% Throttle Deadband
90% Throttle Max
HALF THROTTLE
THROTTLE INPUT (percent)
CONTROLLER OUTPUT (PWM percent)
100908070605040302010 0
100
90
80
70
60
50
40
30
20
10
0
