3 — I/O MAPPING
pg. 37
Return to TOC 1229 Manual - OS 1.8 RevA - May 2021
Example 9: Conguring CANopen to operate with a CANopen compliant tiller head
is example shows how to congure a walkie with a CANopen compliant tiller head that includes
a wigwag throttle, rabbit button, neutral detect switch, redundant belly button switch, horn button,
and additional wigwag and button controls for li/lower.
is conguration using a CANopen tiller head requires that PDO1 RX mapping is set so that data
mapping from the tiller controls is into the User functions in the I/O map, where they their mapping
can then be mapped into other I/O functions as in the other examples. Begin by setting the PDO1
112-User 2
Min = -4095
Max = 4095
111-User 1
Min = 0
Max = 0
113-User 3
Min = –4095
Max = 4095
34-Wig Wag 1 Throttle
35-Wig Wag 1 Throttle
Input = 112
Fwd Min = 53%
Fwd Max = 100%
Rev Min = 47%
Rev Max = 0%
26-Bit Mask 1
Input = 111
Bit = 0
27-Bit Mask 2
Input = 111
Bit = 1
28-Bit Mask 3
Input = 111
Bit = 2
29-Bit Mask 4
Input = 111
Bit = 3
30-Bit Mask 5
Input = 111
Bit = 6
31-Bit Mask 6
Input = 111
Bit = 7
36-Wig Wag 2 Throttle
37-Wig Wag 2 Reverse
Input = 113
Fwd Min = 53%
Fwd Max = 100%
Rev Min = 47%
Rev Max = 0%
93-Reverse
Input = 35
41-Logic Gate 1
AND/OR/XOR = 1 (AND)
Input 1 = 26 (Neutral)
Input 2 = 26 (Neutral)
Input 1- = Off
Input 2- = Off
Output- = On
94-Speed Mode
Input = 28
5-Switch 5
On Delay = 0.1 s
Off Delay = 0.1 s
Normally Closed = On
91-Throttle
Input = 34
Enable Input = 41
Fwd Deadband = 5%
Fwd Max = 97%
Fwd 0% Offset = 3%
Fwd 50% Map = 65%
Rev Deadband = 5%
Rev Max = 97%
Rev 0% Offset = 3%
Rev 50% Map = 65%
Throttle Filter = 100 Hz
HPD Type = 1
SRO Type = 0
HPD Threshold = 3%
HPD Latch = 0.0 s
Sequencing Delay = 0.1 s
PotL Current Check = Off
98-Emergency Reverse
Input N/O = 27
Input N/C = 5
Fwd Only = On
Max Current = 100 %
Dir Interlock = On
Time Limit = 0.5 s
Speed = 15 %
Accel = 1.0s
Decel = 1.0 s
85-Driver 6
Disabled/LowSide/HighSide = 2
Input = 29
Enable Input = 29
86-Driver 3/4 Actuator
Enable = On
Input = 36
Rev Input = 37
Enable Input = 100
Accel = 1.0 s
Decel = 1.0 s
Stop Current = 10 A
Stop Current Time = 1.0 s
Battery Voltage Comp = Off
Throttle
Neutral
Belly Button N/O
Rabbit
Lift/Lower Wigwag
Lift (Sw)
Lower (Sw)
These “bit inputs”
from the tiller switches
are available for other
logic/uses, see the text
for examples.
