2 — INSTALLATION AND WIRING
1229 Manual - OS 1.8 RevA - May 2021
Return to TOC
pg. 16
WIRING EXAMPLES AND DIAGRAMS
Push (and) Push-Too-Fast wiring
• When the keyswitch (KSI) is ON, the Push-Too-Fast will work on all controllers, otherwise
when KSI is OFF, the Push-Too-Fast function will only work on 1229-xx05 models.
Main Contactor and EM Brake Coil wiring
• e 1229-xx05 models must have the Main Contactor and EM Brake coils wired to the
capacitor bank (Vcap) which is the terminal labeled B+ on the cover. On these -xx05 models,
the Driver 1 (pin J1-20) and Driver 2 (pin J1-4) inputs’ yback diodes connect to the capacitor
bank (Vcap).
• Wire all the non-1229-xx05 models in the conventional manner, with the Main Contactor
(Driver 1) and EM Brake (Driver 2) wired to KSI since their construction has the yback
diodes going to KSI.
■ Notice, there is no way for the controller to determine whether the wiring has been
violated, therefore a wiring fault cannot be raised.
Key-Off Decel wiring
• Key-O Decel feature only works with 1229-xx05 models.
Status Beacon wiring
• An External Beacon (indicator for ash codes) on Driver 6 is only available on the 1229-xx05
models since the hardware is dierent (the upper FET in Driver 6 is removed resulting in only
a low-side driver).
Incorrect Driver 1 (pin J1-20) wiring of the MAIN contactor coil will cause internal damage to
the controller.
Incorrect Driver 2 (pin J1-4) wiring of the EM BRAKE contactor coil will cause internal damage to
the controller.
Figure 6 highlights the 1229-xx05 models’ wiring dierences.
Figures 7–9 are example applications that highlight the correct wiring (in red) for the push input,
push too fast, key-o decel, and beacon options. Aer reviewing this section, if the 1229 model in-
hand does not match these described features for its intended application, contact the local Curtis
distributor or the regional Curtis sales-support oce for assistance before proceeding. Wiring a 1229
controller incorrectly will cause internal damage.
