2 — INSTALLATION AND WIRING
1229 Manual - OS 1.8 RevA - May 2021
Return to TOC
pg. 14
Table 4 The Status Beacon Flash Codes
Number Error Name 3100R Error Codes Beacon
1 No Fault N/A SOLID ON
2 HW Failsafe 1 1-1
3 PLD Clock Fail 2 1-2
4 Calibration Reset 9 1-3
5 Main Brake Driver Over Current 10 2-1
6 Main Driver Open Drain 11 2-2
7 EMR Redundancy 12 3-1
8 EEPROM Failure 13 1-4
9 Main Contactor Dropped 15 2-3
10 Current Sensor 16 1-5
11 Main Contactor Welded 17 2-4
12 Encoder 18 3-2
13 PDO Timeout 19 4-1
14 Supervisor Comms 20 4-2
15 Supervisor Watchdog 21 4-3
16 Supervisor Pot1 Fault 22 4-4
17 Supervisor Pot2 Fault 23 4-5
18 Supervisor Pot3 Fault 24 4-6
19 Supervisor PotH Fault 25 4-7
20 Supervisor Sw1 Fault 26 4-8
21 Supervisor Sw2 Fault 27 4-9
22 Supervisor Sw3 Fault 28 4-10
23 Supervisor Sw4 Fault 29 4-11
24 Supervisor Sw5 Fault 30 4-12
25 Supervisor KSI Voltage Fault 31 4-13
26 Supervisor Motor Speed Fault 32 4-14
27 Supervisor Dir Check Fault 33 4-15
28 External Supply Fault 34 3-3
29 EMBrake Driver Open Drain 36 2-5
30 EMBrake Driver On 37 2-6
31 Pot1 Wiper 41 5-1
32 Pot2 Wiper 42 5-2
33 Pot3 Wiper 43 5-3
34 Wiring Fault 49 5-4
35 Severe Undervoltage 50 3-4
36 Controller Severe Undertemp 52 3-5
37 Controller Severe Overtemp 53 3-6
38 Precharge Failed 54 5-4
39 Driver Shorted 70 2-7
40 Driver3 Fault 71 2-8
41 Driver3 Overcurrent 72 2-9
42 Driver4 Fault 73 2-10
