2 — INSTALLATION AND WIRING
pg. 13
Return to TOC 1229 Manual - OS 1.8 RevA - May 2021
e Push-Too-Fast soware will not be generic. e hardware stung option for this feature is
dierent, so only the following model numbers have this feature:
• 1229-3105 24-36V 200A, CAN Terminated, Push-Too-Fast SW
• 1229-3205 24-36V 250A, CAN Terminated, Push-Too-Fast SW
• 1229-4105 48V 200A, CAN Terminated, Push-Too-Fast SW
Existing 1229 models do not have the Push-Too-Fast feature and will only operate as-is when pushed.
e OEM level parameter, 90-Push Input, turns the Push and Push-Too-Fast features On/O. e
generated motor voltage is the basis of the speed limit. is voltage range is selectable between 0V
and the controller’s maximum voltage, e.g. 45V or 60V. In the models that use the Push-Too-Fast
feature, sleep mode is disabled. If the main contactor or battery are missing but Push is enabled, the
controller shorts the motor when the Push-Too-Fast engages (it will not modulate the speed limiting).
Note: e EMR (98-Emergency Reverse) and the inhibit (71-Inhibit Input) are ignored in the
Push operation.
Key-Off Decel
e Key-O Decel function provides a controlled deceleration of the vehicle to zero speed as per
the specied deceleration delay if the keyswitch is turned o while in motion. e key o decel is
the same as and is adjusted with the Interlock Decel High Speed and Interlock Decel Low Speed
parameters. is feature is only available on the 3105, 3205, and 4105 models, since it requires the
special hardware and controller wiring.
Status Beacon
For the Push-Too-Fast models (3105, 3205, 4105), a low-side driver is used to drive a remote Status
Beacon which ashes the fault status. To accomplish this, these models have a specic hardware
option on Driver 6. During normal operation, with no faults present, the Status Beacon will be
steadily on. If the controller detects a fault, the Status Beacon will ash the fault code per the table
below. During a flash code, the beacon will be on for 250ms and flash at 2Hz. There will be 1
second between the rst and second ash number, and 2 seconds between the ash codes (or before
repeating). Table 4 lists both the beacon ash codes and the 3100R gauge codes. See Chapter 8,
Diagnostic & Troubleshooting, for detailed information about fault codes.
Note: the beacon’s ash code is not the same fault number displayed on the 3100R gauge.
