2 — INSTALLATION AND WIRING
1229 Manual - OS 1.8 RevA - May 2021
Return to TOC
pg. 10
1229 LOGIC AND LOW-POWER CONNECTIONS
Pin Name
DESCRIPTION / ü TYPICAL APPLICATION(S)
SPECIFICATIONS (PROTECTED VOLTAGES)
5 Switch 5
Digital (switch) input #5
ü Suitable for a TTL pulse speed (SPD) sensor input
ü An active-low (pull to ground) general purpose
digital switch input
• Frequency: 30 kHz, Max.
• Logic-High threshold: 2.4 volts
• Logic-Low threshold: 1.6 volts
• Input voltage range: –10 to +60 volts
6 Analog GND Analog ground for the analog inputs
• Pot-fault detection
(short to B+)
7 Pot 3
Analog input #3
ü 3-wire potentiometer (3-wire throttle pot, brake,
etc.)
ü 0-5 V voltage input (voltage throttle)
ü Switch input, if referenced to +5V Out (pin J1-18)
• Input voltage range: 0 – 5 volts
(short to B+)
8 KSI
Keyswitch input. Provides the logic power for the
controller and the power for the drivers 1 & 2 internal
coil-returns
• Input voltage range: 10 – 60 volts
• The controller will not turn On if the battery
voltage is below 12V (all models) or above:
48V (24 – 36V models)
64V (48V models)
• The micro resets if KSI voltage is ≤ 4 V
9 TXD Data I/O to 1314/1313 HHP programmers Serial Tx (transmit)
10 Switch 2 Digital (switch) Input #2
• Input current: 2.7mA @ 60 Volts
• Input voltage range: 10 – 60 volts
• Threshold (Off/On):
< 10 volts (Off)
> 10 volts (On)
11 Switch 4 Digital (switch) Input #4
• Input current: 2.7mA @ 60 Volts
• Input voltage range: 10 – 60 volts
• Threshold (Off/On):
< 10 volts (Off)
> 10 volts (On)
12 RXD Data I/O to 1314/1313 HHP programmers Serial Rx (receive)
13 Pot 1
Analog Input #1
ü 3-wire potentiometer (3-wire throttle pot,
brake, etc.)
ü 0-5 V voltage input (voltage throttle)
ü Switch input, if referenced to +5V Out (pin J1-18)
• Input voltage range: 0 – 5.0 volts
(short to B+)
14 Pot 2
Analog Input #2
ü 3-wire potentiometer (3-wire throttle pot,
brake, etc.)
ü 0-5 V voltage input (voltage throttle)
ü Switch input, if referenced to +5V Out (pin J1-18)
• Input voltage range: 0 – 5.0 volts
(short to B+)
15 Driver 5
Digital Output #5
Congurable as:
ü An independent PWM driver
ü Pair with Driver 6 for an independent bidirectional
actuator control
ü Combined with Drivers 3 & 4 to provide two
bidirectional speed and direction dependent
drivers (see Figures 8 & 9)
10 Amp driver:
• High-side Driver (from Vcap)
• Low-side (coil) Driver:
w/Internal yback-diode (to Vcap)
(short to B+)
16 GND Logic ground for programmer or other external devices
Logic Ground
Table 3 Low Current Connections
, cont’d
