2 — INSTALLATION AND WIRING
pg. 9
Return to TOC 1229 Manual - OS 1.8 RevA - May 2021
When designing a vehicle harness and its routing throughout a vehicle, follow these guidelines to avoid
common control-signal interference. Protect the wiring from abrasions due to vibrations, pinch, cut and
pull-lose damage, which can lead to an inoperative controller or vehicle.
CANbus (Pins 1 and 2)
Use the 1229’s CAN port to communicate with other CAN modules. Construct the CANbus using twisted-
pair wires. Keep the CAN wiring away from the high current cables and cross them at right angles when
necessary. In extreme cases, use shielded twisted-pair wire, only connecting the shield-drain wire to the
ground (pin J1-16) on the controller. All generic models are CAN terminated (120Ω) except the 1229-xx51
models (See Table D-1).
Serial bus (Pins 9 and 12)
Use the 1229’s serial port to communicate with the Curtis Instruments’ programming and diagnostic tools.
Keep the routing short. Typically, twisted-pair wiring is not required.
All other low power wiring
Follow battery-powered vehicle wiring practices for the remaining electrical connections. Keep the controller
inputs such as the throttle and switches separate from the controller’s coil-driver wiring. Avoid routing
the low power signal wiring in parallel (alongside/together) with the high power and current battery and
motor cables.
Notice: e 1229 models running the OS 1.7 soware have specic features requiring their installation
and usage in a dened manner. Table 3 characterizes these individual controller connections. e Figures
7–9 example wiring diagrams illustrate how to connect the controller to prevent damage and utilize the
specic features.
Table 3 Low Current Connections
1229 LOGIC AND LOW-POWER CONNECTIONS
Pin Name
DESCRIPTION / ü TYPICAL APPLICATION(S)
SPECIFICATIONS (PROTECTED VOLTAGES)
1 CAN H CANbus High signal
• 120Ω termination is by model
1229-xx01 = WITH CAN termination
1229-xx05 = WITH CAN termination
1229-xx51 = WITHOUT CAN termination
(short to B+ and B–)
2
CAN L CANbus Low signal
3
Switch 3 Digital (switch) Input #3 • Input current: 2.7mA @ 60 Volts
• Input voltage range: 10 – 60 volts
• Threshold (Off/On):
< 10 volts (Off)
> 10 volts (On)
4
Driver 2
Low-side PWM Driver #2
ü EM Brake (coil driver)
Note: see wiring restrictions based upon Model
• Output current: 2 Amps, Max.
• Frequency range: 200 Hz – 1 kHz
• w/Reverse polarity protection
(short to B+ and B–)
• w/Internal yback-diode to KSI:
Models 1229-xxx1
• w/Internal yback diode to Vcap:
Models 1229-xx05
Quick Link:
Table D-1 p.137
