3 — PROGRAMMABLE PARAMETERS
pg. 59
Return to TOC Curtis Model 1226BL – July 2024
PARAMETER
CAN INDEX
VALUES
DEFAULT
RAW VALUES
DATA SIZE DESCRIPTION
Forward Negative Middle Angle
Speed
0xA11D00
0–100%
60%
0–8192
16-bit
Indicates the maximum speed for the Forward Negative
Middle Angle.
Forward Negative Min Angle
0xA11E00
−120.0–0.0°
−30.0°
−21843–0
16-bit
Indicates the angle at which the Forward Negative Min Angle
Speed is used.
Forward Negative Min Angle
Speed
0xA11F00
0–100%
80%
0–8192
16-bit
Indicates the maximum speed for the Forward Negative
Min Angle.
Forward Negative Deadband
0xA12000
−120.0–0.0°
−10.0°
−21843–0
16-bit
Indicates the angle that denes the forward negative deadband
threshold.
Reverse Max Angle
[PCF]
0xA12100
0.0–120.0°
120.0°
0–21844
16-bit
Indicates the angle at which the Reverse Max Angle Speed
is used.
Reverse Max Angle Speed
[PCF]
0xA12200
0–100%
50%
0–8192
16-bit
Indicates the maximum speed for the Reverse Max Angle.
Reverse Middle Angle
[PCF]
0xA12300
0.0–120.0°
60.0°
0–21844
16-bit
Indicates the angle at which the Reverse Middle Angle Speed
is used.
Reverse Middle Angle Speed
[PCF]
0xA12400
0–100%
60%
0–8192
16-bit
Indicates the maximum speed for the Reverse Middle Angle.
Reverse Min Angle
[PCF]
0xA12500
0.0–120.0°
30.0°
0–21844
16-bit
Indicates the angle at which the Reverse Min Angle Speed
is used.
Reverse Min Angle Speed
[PCF]
0xA12600
0–100%
80%
0–8192
16-bit
Indicates the maximum speed for the Reverse Min Angle.
Reverse Deadband
[PCF]
0xA12700
0.0–120.0°
10.0°
0–21844
16-bit
Indicates the angle that denes the reverse deadband threshold.
Reverse Negative Max Angle
0xA12800
−120.0–0.0°
−120.0°
−21843–0
16-bit
Indicates the angle at which the Reverse Negative Max Angle
Speed is used.
Reverse Negative Max Angle
Speed
0xA12900
0–100%
50%
0–8192
16-bit
Indicates the maximum speed for the Reverse Negative
Max Angle.
Reverse Negative Middle Angle
0xA12A00
−120.0–0.0°
−60.0°
−21843–0
16-bit
Indicates the angle at which the Reverse Negative Middle Angle
Speed is used.
Reverse Negative Middle Angle
Speed
0xA12B00
0–100%
60%
0–8192
16-bit
Indicates the maximum speed for the Reverse Negative
Middle Angle.
Reverse Negative Min Angle
0xA12C00
−120.0–0.0°
−30.0°
−21843–0
16-bit
Indicates the angle at which the Reverse Negative Min Angle
Speed is used.
Reverse Negative Min Angle
Speed
0xA12D00
0–100%
80%
0–8192
16-bit
Indicates the maximum speed for the Reverse Negative
Min Angle.
Reverse Negative Deadband
0xA12E00
−120.0–0.0°
−10.0°
−21843–0
16-bit
Indicates the angle that denes the reverse negative
deadband threshold.
SPEED LIMITATION MENU (STEERING SOURCE = 4), cont’d
