3 — PROGRAMMABLE PARAMETERS
pg. 55
Return to TOC Curtis Model 1226BL – July 2024
Parameter PDO CAN Index Default
Length TPDO4
0x1A0300
0
1 TPDO4
0x1A0301
50008h
2 TPDO4
0x1A0302
50008h
3 TPDO4
0x1A0303
50008h
4 TPDO4
0x1A0304
50008h
5 TPDO4
0x1A0305
50008h
6 TPDO4
0x1A0306
50008h
7 TPDO4
0x1A0307
50008h
8 TPDO4
0x1A0308
50008h
Table 4 PDO Mapping Objects — CAN Indexes and Defaults, cont'd
STEERING MENU
e controller provides a steering speed limit function for vehicles equipped with the Curtis 1220E
electric steering controller.
e Steering menu parameters enable the speed limit function and specify the steering speed limit
input. e speed limit is congured by the Speed Limitation menu. How the 1226BL calculates the
speed limit depends upon which input is specied with the Steering Source parameter.
e parameters contained by the Speed Limitation menu also depend upon the specied input. ere
are three variations of the menu, for the following inputs:
• Switch input (Steering Source = 0)
• Analog R input, analog V input, CAN input (Steering Source = 1–3)
• EPS input (Curtis model 1220E, Steering Source = 4). When this input is specied, the EPS
Controller Conguration menu is also displayed.
Note: When a switch or analog input is used, the Steering Sensor menu is also displayed.
e following table describes the parameters on the Steering menu:
STEERING MENU
PARAMETER
CAN INDEX
VALUES
DEFAULT
RAW VALUES
DATA SIZE DESCRIPTION
Enable
[PCF]
0xA13300
Off/On
Off
0–1
8-bit
Indicates whether the steering speed limit feature is enabled.
Steering Source
0xA30200
Enumerated
EPS Input
0–4
8-bit
Species the input that activates the steering speed limit function.
0 = Switch
1 = Analog R Input
2 = Analog V Input
3 = CAN Input
4 = EPS Input
Note: When an analog or CAN input is specied, the Throttle
Type parameter must specify CAN.
