3 — PROGRAMMABLE PARAMETERS
Curtis Model 1226BL – July 2024 Return to TOC
pg. 30
SPEED LIMIT SUPERVISION MENU
PARAMETER
CAN INDEX
VALUES
DEFAULT
RAW VALUES
DATA SIZE DESCRIPTION
Enable
0x391400
Off/On
On
0–1
16-bit
Species whether speed limit supervision is enabled.
If On is specied, you must take the steps in Motor Maximum
Speed: Speed Limit Supervision.
CAUTION: Specifying Off may make the system non-compliant
with EN 1175:2020 and may cause a higher probability of
dangerous failure. Regulatory compliance of the complete
vehicle system, including this setting, is the responsibility of the
vehicle OEM.
Speed Tolerance
0x391500
0%–100%
30%
0–32767
16-bit
Species the speed limit as a percentage above the
initial speed.
Speed Ramp Delay
0x391600
100ms–2000ms
600ms
100–2000
16-bit
Species the interval between when the speed limit is
exceeded and when speed begins decreasing to zero.
Speed Ramp Rate
0x391700
100%–500%
350%
1024–5120
16-bit
Species the slowest allowable ramp transition from the maximum
speed to zero.
Speed Limit HPD
0x391300
Off/On
On
0–1
16-bit
Species whether the controller must enter the neutral state
before limited speed mode can be aborted.
SPEED LIMIT SUPERVISION MENU
e limited speed mode is the speed mode that has lower values for both the Max Speed and Rev Max
Speed parameters (Mode 1 and Mode 2 menus). For example, if speed mode 2’s Max Speed and Rev
Max Speed parameter values are lower than mode 1’s Max Speed and Rev Max Speed values, mode
2 is the limited speed mode.
If both speed modes have identical Max Speed parameter values and identical Rev Max Speed
parameter values, the application will not have a limited speed mode.
Note: If one mode has a higher Max Speed but a lower Rev Max Speed than the other mode, a
Parameter Mismatch fault (type 3) occurs.
e following table describes the Speed Limit Supervision parameters.
Speed Limit HPD
To require the controller to enter the neutral state before aborting limited speed mode, set the Speed
Limit HPD parameter to On. When the speed limit HPD function is enabled and the controller is
running in limited speed mode, the following inputs are aected:
Input Description
Mode
The controller must be in the neutral state before the speed mode can
be changed.
Charger Inhibit
If the Charger Inhibit input is on when speed limit HPD is enabled, the
controller disables traction and hydraulic operations and enters the
limited speed mode.
To abort the limited speed mode, battery charging must stop and the
throttle must be released to neutral.
