2 — INSTALLATION AND WIRING
Curtis Model 1226BL – July 2024 Return to TOC
pg. 24
To connect a motor temperature sensor input, use pin J1-6.
To enable and congure the motor temperature sensor function, use Motor Temperature Control
menu’s parameters.
e following table describes the motor temperature sensor's specications.
Specification Value
Temperature Range −40 – +200°C
Resistance Measurement Range 250~5k
Resistance Measurement Accuracy • ± 20 @ 2k and below
• ± 100 @ 2k and above
Maximum sensor current 2.5mA
CANbus
CAN connections use the following pins:
• CAN Low: J2-1
• CAN High: J2-3
e controller does not have an internal 120Ω CAN terminating resistor. CANbus nodes typically
are wired using a daisy chain topology with 120Ω terminating resistors at each end. If the controller
is the last node in the chain, you should include an external 120Ω terminating resistor in the wiring
harness.
Use the CAN Interface menu to specify the baud rate, Node ID, and heartbeat rate.
e following table describes the specications for the CAN pins.
Specification Value
Baud Rate Following are the minimum and maximum rates:
• Minimum: 125 kb/s
• Maximum: 1 MB/s
Input Impedance > 1k and < 1000pF
Maximum Voltage Depends upon the model:
• 1226BL-22XX and 1226BL-41XX: 58V
• 1226BL-61XX: 100V
Maximum Reverse Voltage −0.5V
For information on the controller’s CANopen features, see the following topics:
• CANopen Communications
• CANopen Object Dictionary
