Packing List
The following items are included in the product package
Double Ball Head
Arm Mount
Gooseneck
Microphone
Headphones
*4 pieces
Users can choose single-ear headphones or double-ear headphones
when ordering.
Transmitter
*4 pieces
Antenna
* 16 pieces
RS232 cable
*4 pieces
SDI cable
*4 pieces
Power supply
cable*4 pieces
Receiver
*1 piece
Antenna
* 4 pieces
RS232 cable
*4 pieces
Power adapter
*1 piece
Metal Stand *1 piece
Power adapter
(12V/2A) *1 piece
Headphones
*4 pieces
Receiver
3081 *1 piece
Network cable
*1 pieces
Notice: The transmitter comes with the Sony NP-F type battery dock and has
preassembled V-mount connector. The receiver has preassembled V-
mount battery plate and V-mount connector.
03
04
Beam-Forming
Combined with 4×4 MIMO and Beam-Forming technology, this product has
advantages over other WiFi products in the market in terms of transmission
distance and video resolution. Beam-Forming technology makes wireless signals
more concentrated and stronger in the direction from which they are transmitted
to the receiver, allowing them to transmit farther and be less susceptible to
interference from other signals, thus making them more stable.
Support RS232/422
This product supports transparent transmission device via RS232/422
interface, which is convenient for users to control the remote device through the
local device at the receiving terminal, such as the PTZ.
controlling
This product supports switching between two operating modes, namely standard
mode and RTSP streaming mode. In standard mode, this product supports
4TX-to-1RX, and the video outputs interface are HDMI and 3G-SDI. In RTSP streaming
mode, this product supports 4TX-to-Multiple RX, and the video streaming interface is
LAN port(RJ45) ..
Standard mode and streaming mode
Voice intercom
Each video transmitter and receiver terminal of the product is equipped with a
3.5mm voice intercom interface. One-to-one full-duplex intercom or one-to-many
broadcast can be performed on the transmitter and receiver terminals. The receiver
hands-free call mode is automatically disactived when the headphones are plugged in.
The headphone jack supports the mainstream four-segment 3.5mm mobile phone
headphones on the market.
