HDMI/SDI
HDMI/SDI
RTSP
14
15
4. The receiver can be powered by both the V-mount lithium battery and DC-IN port via
the affiliated power adapter. If the mentioned two types of power supply are
connected at the same time, the lithium battery is prioritized in power supplying,
and the battery will switch to the power adapter for power supplying automatically
after the battery power is exhausted.
This system supports tally function. When tally input is connected to GND, tally out
will be 5V voltage, which can provide 200mA max source current. And when tally
input is OPEN(disconnected to GND), tally out will be low.
Power
Li-battery
Product Application
Standard mode
In standard mode, the four channel video sources are connected to the four
transmitters via HDMI or SDI cable respectively. The receiver will receive the four
channel signals and transport them to switch console or/and monitor via
HDMI SDI.or/and
Headphone
Camera-1
TX-1
Headphone
Camera-2
TX-2
Headphone
Camera-3 TX-3
Headphone
Camera-4 TX-4
500m/1640ft
Four channel
Full-HD in One
RF Channel
RX-1
RX-2
*Tally
*RS232/422
Monitor
Switch Console
Live Streaming network
Headphone
