Crux Interfacing Solutions • 21541 Nordhoff Street, Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.072419
6 of 12
R
INTERFACING SOLUTIONS
ACPBM-77X
27. If your vehicle has a factory AUX
input, use the 3.5mm to RCA Adapter
included in the kit to connect sound to
the factory audio system.
26. Connect the audio out RCAs from
the Power/Video harness to the RCA
inputs that were installed earlier.
28. Mount the microphone to a
locaon of your choice.
29. Connect the 3.5mm microphone
jack to the MIC input on the Power/
Video harness.
30. Connect the 4-pin connector from
the Power/CAN harness to the UART
port on the Smart-Play module.
31. Connect the Power/Video harness
to the POWER/VIDEO port on the
Smart-Play module.
34. Check the OSD sengs and make
sure they match those on the next
page. Test the Back-Up camera. Put
gear in reverse and check for rear
camera image on screen. Go to Smart-
Play mode and test for funconality.
Once the cameras and Smart-Play
validaon is complete, mount the
ACPBM-77X and Smart-Play modules.
And nally, reinstall all the components
to their original set-up.
32. Route the USB cable to a desired
locaon and connect it to your
smartphone’s lightning cable.
33. Test the communicaon. Turn on
the ignion and check if LEDs are on.
Smart-Play Integration with Rear-View Camera Input for
E Series BMW with CCC Systems (6.5” or 8.8” Monitor) and 10-Pin LVDS Connector
