CRUX ACPBM-77X handleiding
Handleiding
Je bekijkt pagina 12 van 12
Crux Interfacing Solutions • 21541 Nordhoff Street, Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.072419
12 of 12
R
INTERFACING SOLUTIONS
ACPBM-77X
VEHICLE APPLICATIONS:
Smart-Play Integration with Rear-View Camera Input for
E Series BMW with CCC Systems (6.5” or 8.8” Monitor) and 10-Pin LVDS Connector
2007 - 2011 1 Series 3-door hatchback
2007 - 2013 1 Series 2-door coupe (1M)
2004 - 2012 1 Series (5-door)
2008 - Up 1 Series Converble
2005 - 2011 3 Series Sedan
2005 - 2011 3 Series Wagon
2006 - 2013 3 Series Coupe
2007 - UP 3 Series Conveble
2004 - 2010 5 Series Sedan
2004 – 2007 5 Series Wagon
2004 - 2010 6 Series Coupe
2004 - 2010 6 Series Conveble
2007 - 2013 X5 Sports Acvity Vehicle
2008-2011 X6 Sports Acvity Coupe
Plug and Play Installa
Media Controller with controls by factory infotainment (iDrive)
Rear-view camera input
Front camera input
Front camera inpu
t can also be used as an Auxiliary Video Input
Manual switching to rear-view camera (only for vehicles with PDC buon)
Manual return from rear-view and front camera (cancellaon of automaswitching)
2 trigger outputs (+12V max. 1A), separately adjustable switching events (CAN, ACC, camera,
reverse gear)
Picture-in-picture mode combining amarket rear-v
iew and front camera picture(s) with factory
parking sensor graphics
Compable with all factory video accessories (e.g. rear-view camera, Top-View Camera System)
E-series with Navigan System or radio with 6.5“ or 8.8“ monitor and 10-PIN LVDS Connector
1 / 10
Rev.040816
Interface Box
BM-77D Harness
Power/CAN Harness
LVDS10 Cable
1 SERIES
BMW
5 SERIES
6 SERIES
X SERIES
3 SERIES
