ACPAD-81Y
Smart-Play Integration with Multi Camera Inputs & USB Player
for AUDI Vehicles with MMI MIB/MIB2 Systems
Seng the Rear Aermarket Camera
(Use the PINK (12V Output 1) wire to power the Rear camera)
In the OSD Menu, set “Opon 1” > menu item “Power
Out 2” to “CAM”
OSD Menu Menu Item Seng Descripon
Input RVC
OFF Rear View camera deacvated
ON
Switches to rear-view camera if reverse gear is engaged
or PDC is acvate
Opon 1 Park Logic
Intelligent
For vehicles with PDC. Enabled while parking process
and up to 12 mph (not suitable for front camera
operaon for vehicles without front PDC)
RGearOnly
Enabled while parking process
(not suitable for front camera operaon)
RGearSpeed
Enabled while parking process and up to
e.g. 7 mph (speed adjustable)
RGearTime Enabled while parking process and up to 20 seconds
Opon 1 RVC Lines ON Interacve lane lines acvated
Opon 2 R/F Cam Till XX Speed seng for deacvang of the camera image
Opon 2 PDC Graphic
OFF OEM PDC display of the vehicle deacvated
Horizontal Vehicles with horizontal OEM PDC display
Vercal Vehicles with vercal OEM PDC display
Opon 2 Cam Trigger
CAN Rear gear and blinker signal detecon over CAN Bus
Analog Rear gear signal detecon over analog +12V signals
Note: You can deacvate the camera image by a long press (2 sec.) of the MMI knob.
