16 • Installation and Setup of Crestron RF Products Best Practices – DOC. 6689H
The example below shows a channel map based on the “Chanalyzer Capture of Total RF
Interference Sample
” on page 12.
Channel Map Example
NETWORK
CHANNEL NUMBERS
infiNET EX/ER
CHANNELS 2.4 GHz Wi-Fi CHANNELS
Eliminated due to
interference
11
1
12
2
13
3
14
4
infiNET EX & ER
handheld remotes
15
5
Guest Network
16
6
17
7
18
8
19
9
infiNET EX & ER
handheld remotes
20
10
Personal Computer
21
11
22
23
24
25
Lighting
26
In the channel map example, enter wireless networks as follows:
1. Too much interference exists on Wi-Fi channel 1 and on 802.15.4 channels 11–14;
therefore, those channels are eliminated.
2. Wi-Fi channel 6 is the channel that has the least interference; therefore, a guest
network uses that channel. The 802.15.4 channels 16–19 are then unavailable to
any other devices.
3. Channel 11 is the only free Wi-Fi channel remaining for a personal computer Wi-Fi
network. The 802.15.4 channels 21–24 are then unavailable to any other devices.
4. There are no more free Wi-Fi channels remaining for devices that communicate in
the 802.11 network; therefore, the 802.11a (5 GHz) channels are selected for any
remaining Wi-Fi devices.
5. The 802.15.4 channel 20 is free; therefore, the infiNET EX & ER handheld remote
networks are set to that channel.
6. The 802.15.4 channel 15 is free; therefore, the infiNET EX & ER handheld remote
networks are set to that channel.
