46 • Horizon® 2 Dimmers, Switches, and Keypads Product Manual — Doc. 9243B
Range (typical) 150 ft (46 m) indoor, 250 ft (76 m) outdoor to nearest mesh network device;
Subject to site-specific conditions and individual device capabilities
1
Gateway Requires a Crestron Wireless Gateway (sold separately)
Connections
Load (1) Screw clamp terminal, consists of (2) wire inserts and (1) red screw head;
Load output;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Line (1) Screw clamp terminal, consists of (2) wire inserts and (1) black screw head;
Line power input;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Neutral (1) Screw clamp terminal, consists of (2) wire inserts and (1) silver screw head;
Neutral input;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Remote (1) Screw clamp terminal, consists of (2) wire inserts and (1) blue screw head;
Remote input from HZ2-AUX or HZ2-KPEX;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Ground (1) 12 AWG flying lead, Class 1, green with yellow stripe;
Ground;
Wire nut included
Environmental
Temperature 32° to 86°F (0° to 30°C)
Humidity 10% to 90% RH (noncondensing)
Construction
Mounting Mounts in a 1- to 4-gang U.S. electrical box (not included);
3.5in. (26mm) electrical box depth recommended;
Derating required in multigang applications
Faceplate Requires a Horizon®2 faceplate (HZ2-FP-G, sold separately, metal backplate included
with faceplate);
Multigang installations require a 2-, 3-, or 4-gang Horizon® 2 faceplate with metal
backplate (HZ2-FP-G, sold separately);
The metal backplate is required for all installations where the electrical box is flush
with or recessed from the wall surface;
The metal backplate is not recommended for electrical boxes that protrude beyond
the wall surface
Dimensions
Height 4.13 in. (105 mm), air-gap switch extends 0.26in. (7mm) from bottom of keypad
Width 1.80 in. (46 mm)
Depth 1.75in. (45mm) overall, extends 0.44in. (12mm) from wall surface when installed
Weight
7.4 oz (208 g)
